57BL55S06-230 24V 60W 3000RPM Brushless DC Motor And Driver Complete Set For Automation Equipment
Product features
● High Efficiency & Energy Saving: Brushless design eliminates mechanical friction loss, achieving an energy conversion efficiency of 85%-95% (compared to 60%-70% for traditional brushed motors). Long-term operation significantly reduces energy consumption costs and supports energy conservation.
● Long Service Life & Durability: No brush wear or operating sparks, with a service life of over 10,000 hours—3-5 times longer than traditional brushed motors. It minimizes equipment downtime for maintenance and lowers overall operational costs.
● Compact Structure: Small in size and lightweight, featuring flexible installation. It balances power performance with portability, ideal for equipment with limited space.
● Wide Application: Suitable for automation processing fields such as grinding, cutting, and drilling, providing stable and reliable power output for various general-purpose automated equipment.
Product parameters
|
ITEM |
SPEC |
UNIT |
|
PHASE |
3 |
PHS |
|
VOLTAGE |
24 |
VDC |
|
Rotor poles |
4 |
pole |
|
Resistance @25℃ |
0.42±10% |
Ω |
|
INDUCTANCE |
1.72±20% |
mH |
|
NOLOAD SPEED |
4500REF |
RPM |
|
NOLOAD CURRENT |
0.500EF |
A |
|
RATED SPEED |
3000 |
RPM |
|
RATED POWER |
100 |
W |
|
RATED TORQUE |
0.32 |
N.m |
|
RATED CURRENT |
5.9 |
A |
|
INSULATING STRENGTH |
500 |
VAC |
|
IP CLASS |
IP40 |
- |
|
INSULATION CLASS |
B |
- |
|
WEIGHT |
600 |
g |
|
Mechanical Dimensions |
Specification |
|
Flange Size |
57mm |
|
Mounting Hole Spacing |
47mm |
|
Boss Diameter |
38mm |
|
Shaft Diameter |
8mm |
|
Shaft Type |
Flat Milled Shaft (D-Shaft) |
|
Flat Milling Depth |
0.5mm |
|
Flat Milling Length |
7.5mm |
|
Shaft Length |
22mm |
|
Motor Body Length |
75mm |
