48V 50W 3000rpm High-Power BLDC Motor + Driver Set - Model 80BL110S50-430/ZM-6618
Product features
● High Efficiency & Energy Saving: Brushless design eliminates mechanical friction loss, achieving an energy conversion efficiency of 85%-95% (compared to 60%-70% for traditional brushed motors). Long-term operation significantly reduces energy consumption costs and supports energy conservation.
● Long Service Life & Durability: No brush wear or operating sparks, with a service life of over 10,000 hours—3-5 times longer than traditional brushed motors. It minimizes equipment downtime for maintenance and lowers overall operational costs.
● Compact Structure: Small in size and lightweight, featuring flexible installation. It balances power performance with portability, ideal for equipment with limited space.
● Wide Application: Suitable for automation processing fields such as grinding, cutting, and drilling, providing stable and reliable power output for various general-purpose automated equipment.
Product parameters
|
ITEM |
SPEC |
UNIT |
|
PHASE |
3 |
PHS |
|
VOLTAGE |
48 |
VDC |
|
Rotor poles |
4 |
pole |
|
Resistance @25℃ |
0.25±10% |
Ω |
|
INDUCTANCE |
1.4±20% |
mH |
|
NOLOAD SPEED |
4000REF |
RPM |
|
NOLOAD CURRENT |
1.5REF |
A |
|
RATED SPEED |
3000 |
RPM |
|
RATED POWER |
500 |
W |
|
RATED TORQUE |
1.6 |
N.m |
|
RATED CURRENT |
14.8 |
A |
|
INSULATING STRENGTH |
500 |
VAC |
|
IP CLASS |
IP40 |
- |
|
INSULATION CLASS |
B |
- |
|
WEIGHT |
2.2 |
Kg |
|
Mechanical Dimensions |
Specification |
|
Flange Size |
80mm |
|
Mounting Hole Spacing |
65mm |
|
Boss Diameter |
62mm |
|
Shaft Diameter |
14mm |
|
Shaft Type |
Single-keyway Shaft |
|
Key Width |
5mm |
|
Flat Milling Length |
25mm |
|
Key Length |
35mm |
|
Motor Body Length |
110mm |
